Measuring with a ruler not starting at zero, in inches

An example figure from the Length Reading Generator.

A 6 inch ruler marked in quarter inches with a metal cylinder lying along it from 1 inch to 3 1/2 inches, with magnified views of both ends — A 6 inch ruler marked every quarter inch, with a metal cylinder lying along it from the 1 inch mark rather than 0. Magnified views show its left end on 1 inch and its right end on 3 1/2 inches, so students subtract to find its length.

Edit this figure Download PNG

Editing opens it in the Length Reading Generator with these settings, to change anything and copy or download your own.

Answer key

Left end: 1 in
Right end: 3 1/2 in
Length: 2 1/2 in

Free to use in your tests, worksheets, slides or anything else. Open source under Apache 2.0. How to reuse our figures

More Length Reading examples

Make your own in the Length Reading Generator →
